Description
The world’s most reliable small animal ventilator.
- 22 Years of Proven Clinical Application
- Inverted bellows, ascending during exhalation as used in human anesthesia ventilators
- Flow rate adjustable from 0- 120 Liters per minute with expanded range of flow rate selectivity
- Microprocessor Based Ventilator
- Robust LCD Display
- Compatible with Most Anesthesia Systems
- Enhance the administration of inhalation anesthesia
- Essential for extended surgeries or patients with compromised lung function required for cleaning
- Optional M.R.I. conditional (No electric, purely pneumatic / air powered)
Technical Specifications
Classification
A microprocessor based, electronic, time cycled, pressure limited, anesthesia ventilator
Bellows Orientation
Ascending
Volume
Selectable – 200 – 2,200ml
Optional: Pediatric Bellows Optional 50 – 300ml
Optional: Expanded Bellows – 200 – 3,000ml
Controls
- Inspiratory Time – .1 to .3 seconds
- Inspiratory Flow – 1 – 120 LPM
- Inspiratory Pressure Rate – 10 – 80cm H20
- Rate – 2 – 80 BPM
- Pneumatic Manual Push
- Button for Inspiration
LED Display
- Inspiratory Time Indicator
- Rate (BPM)
- I:E Ratio
Alarms and Alerts
- Failure to Cycle – Visual Audible Alarm
- Low Gas Pressure Failure – Visual Audible Alarm
- Power Failure – Visual Audible Alarm
Safety System
Overpressure Governor 80cm H20 (adjustable)
Gas Scavenger
19mm port
Size & Weight
- 12” Width (30 cm) x 11” Depth (28 cm) x 16” Height (41 cm)
- 10 lbs. (4.5 kg)
Options
- Available in MRI Conditional Model
