Description

The Compound 3001-LED Trinocular Microscope delivers outstanding optical performance, value and resolution to meet the exacting standards of life science professionals and students.
With a newly designed infinity plan optical system, a best in class 20mm field of view and a super-bright 3 watt LED illuminator, the 3001-LED Trinocular Microscope provides high contrast images with outstanding resolution, precision design and enhanced illumination.


Ease of Viewing

Newly designed plan achromat focusable eyepieces, with a large 20mm field of view allow users to see more quickly.


Optical Excellence

ACCU-SCOPE’s new infinity plan objectives provide users with high resolution, high contrast objectives at an affordable price. Objectives are available in plan achromat and plan phase configurations.


Illumination

A super, bright white LED light provides over 15 years of illumination saving time, energy and the cost of replacement bulbs.



Specifications

Viewing Head

  • Trinocular (50/50 light split)

Optical System

  • Infinity Optical System, f = 180mm
  • Anti-MoldViewing Head
  • Siedentopf type, inclined 30 ; interpupillary distance adjustment 48-75mm, 360 rotatable
  • Available in binocular or trinocular configurations

Eyepieces

  • HWF Plan 10x eyepiece, 20mm field of view with built-in diopter adjustment; a pointer is standard in one eyepiece.
  • Eyepieces are locked-in to prevent classroom tampering
  • Eyepiece accepts a 20.5mm reticle

Nosepiece

  • Reseved, quadruple, ball bearing with wide rubber grip for easy rotation

Stage

  • Mechanical stage, 140 x 132mm with X-Y movement range of 73 x 50mm

Condenser

  • N-A- 1.25 Abbe condenser with options for phase and darkfield sliders

Stand

  • Cast alloy aluminum

Illumination

  • 3 watt LED with variable intensity control; LED bulb is rated for over 25,000 hours of continued use

Focusing System

  • Coaxial focusing system with adjustable tension control and upper limit stop to prevent accidental damage to slides; all metal gears, brass fine focus gear

Accessories

  • Dust cover, immersion oil and instruction manual, universal power supply 110v-240v

Optional Accessories

  • Plan achromat objectives: 20xR, 50xR oil and 60xR
  • Plan phase objectives: 10x, 20xR, 40xR and 100xR oil
  • Phase contrast sliders: 10x/BF/40x and 20x/BF/100x
  • Darkfield slider (4x – 40x)
  • Reticles
  • Simple polarizer/analyzer
  • Field diaphragm, 5 hole nosepiece
  • Microscope carry case
