Description

VXR is an easy-to-use X-ray system suitable for all main types of veterinary exams. The float-top table with four-way motion features a compact, fixed-height column, allowing quick positioning for all common views. Additional accessories and options support all your needs.

Column Stand

  • Column height: 1950.0 mm (76.8 in.)
  • SID: 1000 mm
  • Monobloc rotation on its (X) axis (optional): ± 45°

Table Weight & Dimensions

  • Weight: ~ 198 kg (436 lb)
  • Dimensions: 150.0 x 96.5 x 195.0 cm (59.1 x 38.0 x 76.8 in.)

X-ray Generator

  • Type: High Frequency monobloc
  • Maximum power: 30 kW (300 mA – 100 kV @ 100 msec)
  • Maximum voltage: 125 kV
  • Maximum mAs: 315 mAs
  • Maximum mA: 400 mA
  • Monobloc maximum thermal dissipation: 55 W
  • Frequency: 40 kHz
  • Total filtration: > 2.50 mm (0.09 in.) Al @ 75 kV

X-ray Tube

  • Type: Rotating X-ray tube
  • Focal spot size: 0.6 mm−1.3 mm (0.02 in. – 0.05 in.)
  • Maximum voltage: 130 kV
  • Anode angle: 15°
  • Anode heat storage capacity: 75.6 kJ (107 kHU)
  • Maximum anode cooling capacity: 300 W

Control Console

  • Type: Microprocessor controller console
  • Display type: 8 in. Color Touch Screen Tablet
  • Display resolution: 1280 × 800 pixels
  • 3 Preset anatomical programs: Dog, Cat, Exotic animals
  • Languages available: Italian, English, Spanish, French, Portuguese (Iberian), German, Greek, Polish, Dutch, Danish, Finnish, Norwegian, Portuguese (Brazilian), Swedish

Horizontal Table

  • Table top dimensions: 1500.0 x 630.0 mm (59.0 x 24.9 in.)
  • Longitudinal travel: 720 mm (± 360 mm) / 28.3 in. (± 14.2 in.)
  • Transversal travel: 170 mm (± 85 mm) / 6.7 in. (± 3.3 in.)
  • Brakes: Mechanical
  • Table top – floor distance: 800.0 mm (31.4 in.)
  • Table top – Digital Detector distance: 65.0 mm (2.6 in.)

Technical Specifications

3-Point Operation Mode (kV — mA — time)

  • kV selection: from 40 to 125 kV [1kV step]
  • mA selection: from 25 mA to 400 mA [13 steps]
  • Time selection: from 0.001 sec to 6.3 sec [35 steps]

2-Point Operation Mode (kV — mAs)

  • kVp selection: from 40 kV to 125 kV [1 kV step]
  • mAs selection: from 0.1 mAs to 315 mAs [28 steps]

Power Supply

  • Voltage: 230 VAC single phase (115 VAC single phase on request)
  • Frequency: 50/60 Hz
  • Current consumption: 16 A max.
  • Total line resistance: 0.40 Ohm max.
  • Automatic line compensation: ± 10%

Exposure Control

Two-step pedal


Safety and Protection

  • Automatic control and protection of the filament current
  • Over current protection
  • Overvoltage protection
  • X-ray tube overload protection
  • Monobloc kHU automatic survey (kHU%)
  • Errors alarms with translated descriptions

Collimator

  • Manual collimator
  • Adjustment from 0 x 0 to 43 x 43 cm (16.9 x 16.9 in.)
  • High intensity LED light (250 lux) for X-ray field simulation
  • Automatic LED light switches off after 30 seconds
  • Retractable tape

Options

  • Stationary grid, 103 L/inch, R=10:1, F=100 cm
  • ±45° monobloc rotation
  • “Tie down” clam cleats
  • 1600 mm length table top
  • Table top with Uro-track for liquid constraint
