Description
A versatile, multipurpose examination light for clinics, medical practices and laboratories. The lightweight, triangular-shaped light head is directed via an ergonomic handle for precise positioning, maintaining a perfectly round light field with maximal light output and excellent shadow dilution.
Key Features:
– Uniform and concentrated light patch: 130,000 Lux maximum at 1M distance
– 4,000 – 5,300K adjustable color temperature
– Colour rendering index fixed at 93, White + Yellow LEDs
– No heat dissipation for improved patient comfort and safety
– LED life more than 80,000 hours
– Angled shape for easy positioning in a crowded surgical theater
– Sleek, curved surface for easy cleaning and spray disinfection
Technical Specifications:
– Working Voltage: 95V-245V, 50/60Hz
– Light Intensity at EC (1 Meter): 13,000 – 130,000 Lux
– Light Intensity Control: 10 – 100% (10 steps)
– Light Field Diameter at EC (1 Meter): 130 – 190mm (adjustable)
– Light Head Diameter: 335mm = 13.19″
– Number of LEDs: 16pcs (Osram Brand), 7pcs White + 9pcs Yellow
– LED Bulb Size Diameter: 35mm
– Life Span of LEDs: 80,000 hrs
– Colour Rendering Index Ra: 93
– Endo / Practice Mode Light: 6pcs Yellow + 1pc White LEDs
– Illumination Depth 20%: 1200mm / 60%: 650mm
– Max. Radiation in Field at 1 Meter: 264 W/m2
– Temperature Increase in Head Area: <=1C
- Arm Angle Adjustment: Up 45deg, Down 50deg, 1100mm
Available Mounting Options: Single Ceiling, Double Ceiling, Wall Mounted, and Portable Mobile (with optional 4-hour battery back-up).
